Wireless Media's MS641 series is a high-performance 4K 60Hz multi-image video processor with remote keyboard/mouse control. It is designed for displaying and controlling up to four sources simultaneously in a variety of customizable layouts. Meantime, with the KVM daisy-chain capability, it support mouse roaming and control among max sixteen sources, with the superior video processor and KVM control performance. It's widely used in operation stations like from space flight, civil aviation, fire alarm, military, and etc.

Description


Main Features:


Accept upssss to 4×HDMI inputs, 2×DP inputs, 1×HDMI 2.0 out

Support 4K 60 frmps/HDCP2.2/4:4:4 in and out

Combines up to four 4K video inputs onto a single stunning display

Windows layout can be customized as wanted

Available to capture a certain part of source to display

Mouse roaming, seamlessly navigate the mouse to any windows to operate

Independent audio and video source selection

Controlled by RS232, web page, front panel




System Diagram





Specifications


Video

Input   Interface

4 × HDMI IN, 2 x DP IN.   2xUSB 2.0 IN (MS641KVM-2)

Input Specification

HDMIHDMI 2.0a

DisplayPort: DP1.2a

HDCP: HDMI 2.0, DP 1.4

USB: USB 2.0 (MS641KVM-2)

Input Resolution

Up to 3840 x   2160@60Hz

Input   Electrical Level

0.5-1.0 V peak to peak   value

Output   Interface

1 x HDMI OUT, 6xUSB 2.0   OUT (MS641KVM-2)

Output Specification

HDMI 2.0

Output Resolution

Up to 3840 x   2160@60Hz

Output   Impedance

100 Ω

DDC Signal

1.2 V peak to peak   value

Audio

Input   Interface

6 x 3.5mm stereo jack

Output   Interface

1   x 3.5mm stereo jack

1   x optical fiber terminal

General

Power Supply

110~240V AC

Power   Dissipation

15W

Control   Mode

RS232LAN

Work Temperature

0°C to 35°C (32°F to 95°F)

10% to 90%, no condensation

Storing   Temperature

-20°C to 70°C (-4°F to   140°F)

10% to 90%, no condensation

Product size

(L x W x   H)

440mm x 272mm x 43.5mm

Product   Weight

3.16kg
